SnowEx 1575 Tailgate Salt Spreader Diagram

Instructions for SnowEx parts lookup: Hover over an index number of your choice to see pricing and availability. In some cases, an aftermarket SnowEx 1575 part may be available.

Parts List Key
	Recommended Alternative Part Is Available

Diagram #	Part #	Description	Online Price
1	D6546	L Warning GVWR	$0.00	View on RCPW
2	D6547	Do Not Move Spreader Danger Decal	$0.00	View on RCPW
3	D6545	No Step Decal	$0.00	View on RCPW
4	D6544	Rotating Parts Warning Decal	$0.00	View on RCPW
5	D6335	Rotating Auger Warning Decal	$0.00	View on RCPW
6	D6548	Read Owner's Manual Warning Decal	$0.00	View on RCPW
7	D4122-1	3/8"-16 x 1-1/2" Bolt	$3.84	View on RCPW
8	0D5100	Muffler Heat Shield	$81.20	View on RCPW
9	75661	Auger Kit	$213.46	View on RCPW
10	75658	Vibrator Motor Mount	$55.53	View on RCPW
11	75657	Baffle Kit	$59.21	View on RCPW
12	D5115-1	5/8" Flat USS Nylon Washer	$5.39	View on RCPW
13	D5706-1	5/16"-18 Serrated Flange Nut	$1.45	View on RCPW
14	D6105	Flexible Draw Latch	$24.93	View on RCPW
15	D6137-1	5/16"-18 x 1-1/4" Screw	$5.44	View on RCPW
16	D6140-1	5/16"-18 x 3/8" Set Screw	$3.44	View on RCPW
17		Discontinued
18	D6166-1	5/16"-18 x 1" Bolt	$2.01	View on RCPW
19		Discontinued
20		Discontinued
	Z-80	80 lb. "Sure-Flow" Salt Spreader Vibrator (No Wiring)	$171.03	View on RCPW
21	D6198	Latch Keeper	$9.67	View on RCPW
22	75630	SP-575X Lid Kit	$210.51	View on RCPW
23	75655	Top Screen Kit	$181.29	View on RCPW
24	D6394-1	5/16"-18 KEPS Zinc Nut	$2.61	View on RCPW
25	D6553-1	#10 x 3/4" HWH Slotted Screw	$1.45	View on RCPW
26	D6584-1	3/8"-16 Serrated Nut	$1.70	View on RCPW
27	D6978-1	3/8"16 x 3/4" Hex Head Bolt	$4.36	View on RCPW
28	75653	Frame Kit	$1,138.27	View on RCPW
29	75653	Frame Kit	$1,138.27	View on RCPW
30	D5107	SP-1575 Auger Motor Cover	$91.59	View on RCPW
31	75662	Material Chute Kit	$52.60	View on RCPW
32	75663	CE Guard Kit	$18.99	View on RCPW
33	75663	CE Guard Kit	$18.99	View on RCPW
34	D5140	Spinner Motor Enclosure Cover	$27.74	View on RCPW
35	D5535-1	1/2"-13 Serrated Flange Nut	$3.84	View on RCPW
36	75640	Transmission Kit	$367.27	View on RCPW
	133001-081	Cogwell Gearbox Spinner Transmission	$266.97	View on RCPW
37	51030	1/4"-20 x 1/2" Stainless Steel Serrated Hex Bolt	$8.66	View on RCPW
38	51031	1/4"-20 x 3/4" Serrated Bolt	$8.66	View on RCPW
39		Discontinued
40		Discontinued
41	0D6214	Rubber Shield Mount	$11.69	View on RCPW
42	D6232	Motor Drive Coupler	$18.54	View on RCPW
	100005	Replacement Motor/Transmission Coupler for SnowEx Spreaders	$12.73	View on RCPW
43	75665	Deflector Kit	$62.81	View on RCPW
44	75660	5/8" 4-Bolt Flange Bearing Kit	$65.74	View on RCPW
45	D6333-1	3/16" x .354 Black Rivet	$2.77	View on RCPW
46	D6452-1	3/8"-16 x 1" Serrated Bolt	$4.27	View on RCPW
47	D6467-1	1/4" x 3/4" x 1/2" Retainer	$2.34	View on RCPW
48	75670	Auger Transmission Kit	$557.04	View on RCPW
49	D6584-1	3/8"-16 Serrated Nut	$1.70	View on RCPW
50	D6651	Motor Connector Adapter	$22.07	View on RCPW
51	D6746	3/16" x 1-1/4" Clevis Pin	$5.20	View on RCPW
52	75618	Spinner Kit	$37.09	View on RCPW
53	D6781-1	5/16"-18 Black Nylon Nut	$3.36	View on RCPW
54	D6874-1	1/4" x 1-1/2" Screw	$2.70	View on RCPW
55		Discontinued
56	D4116-1	1/2"-13 x 1-1/2" Bolt	$6.49	View on RCPW
57	D4119-1	1/2" Flat USS Zinc Washer	$2.71	View on RCPW
58	D4133	5/16" x 1-9/16" Zinc Linch Pin	$15.50	View on RCPW
59	D4135	.093" x 2-3/8" Hairpin Cotter	$2.26	View on RCPW
60	75620	Hitch Pin Kit	$25.66	View on RCPW
61	75620	Hitch Pin Kit	$25.66	View on RCPW
62	75654	2" 3-Point Receiver Hitch	$346.49	View on RCPW
63	D6527	Vee Pro SP-8000 Controller	$745.56	View on RCPW
	9032021	Replacement SnowEx Spreader Controller for SP1575, SP1875 & More	$491.00	View on RCPW
64	D6124	Bracket Knob	$15.24	View on RCPW
65	D6329	1875 Controller Mounting Bracket	$54.11	View on RCPW
66	D6341	156" Pro Control Power Cable	$135.84	View on RCPW
67	D6322	311" Vehicle Harness	$399.79	View on RCPW
68	75676	Spreader Harness Kit	$129.07	View on RCPW
69	D6343	Pro Dust Cover	$22.17	View on RCPW
70	D6170	6" Anderson Connector with Leads	$47.14	View on RCPW
71	D6237	Power Switch for 1875/VP	$18.26	View on RCPW
72	D6354	3-Terminal Vibrator Switch	$20.70	View on RCPW

SnowEx 1575 Tailgate Salt Spreader Diagram
