SnowEx SP-85 Walk Behind Salt Spreader Diagram

Instructions for SnowEx parts lookup: Hover over an index number of your choice to see pricing and availability. In some cases, an aftermarket SnowEx SP-85 part may be available.

Parts List Key
	Recommended Alternative Part Is Available

Diagram #	Part #	Description	Online Price
1	D6509-1	5/16" Rubber Coated Clamp	$17.46	View on RCPW
2	D5903	15" x 16" Screen	$26.01	View on RCPW
3	D5900	2.0 Cubic Foot Yellow Hopper	$193.99	View on RCPW
4	D5940	3/4" Clamp with 3/8" Hole	$5.44	View on RCPW
5	D5931	6-1/4" Material Deflector	$15.87	View on RCPW
6	D5932	6-1/4" Material Deflector	$15.87	View on RCPW
6a	D5932	6-1/4" Material Deflector	$15.87	View on RCPW
7	D6041	2.0 Cubic Foot Hopper Cover	$35.59	View on RCPW
8	T15049-1	5/16"-18 x 1/2" Bolt	$2.60	View on RCPW
9	51009	5/16" Stainless Steel Flat Washer	$108.46	View on RCPW
10	50971	5/16"-18 Nylox Stainless Steel Nut (5 pack)	$7.21	View on RCPW
11	50911	Stainless Steel Hex Cap Screw 1/4-20 x 1-3/8 (5 pack)	$8.66	View on RCPW
12	50969	1/4" Stainless Steel Flat Washer	$8.66	View on RCPW
13		Discontinued
14	D5942-1	1/4"-20 Hex Stainless Nut	$1.23	View on RCPW
15	D5951	Deflector Support Bracket	$11.56	View on RCPW
16	11235	2.0 Cubic Foot Hopper Frame	$114.93	View on RCPW
17	50935	Nylon Wheel Bushing	$8.63	View on RCPW
18	50915	3/4" x 24.3" Axle	$44.83	View on RCPW
19	50907	13" x 5" Push Spreader Wheel	$73.79	View on RCPW
20	50957	3/16" x 1-1/2" Stainless Steel Cotter Pin	$8.66	View on RCPW
21	50963	Stir Wire	$7.21	View on RCPW
22	88261	WB Gear Kit	$44.83	View on RCPW
23	50916	3/8" x 8-1/2" Spinner Shaft	$26.01	View on RCPW
24	88270	Axle Spacer	$2.23	View on RCPW
25	88261	WB Gear Kit	$44.83	View on RCPW
26	88261	WB Gear Kit	$44.83	View on RCPW
27	88263	1-1/2" Diameter Bevel Gear	$15.87	View on RCPW
28	88267	Spinner Shaft Support	$1.64	View on RCPW
29	88261	WB Gear Kit	$44.83	View on RCPW
30	50947	5/32" x 1" Spring Pin	$8.66	View on RCPW
31	50946	Spring Pin 5/32 x 3/4	$8.66	View on RCPW
32	50934	3/16" x 1-1/4" Spring Pin	$8.66	View on RCPW
33	88271	12" x 3/8" Spinner Shaft	$15.89	View on RCPW
34	50933	3/16" x 2" Stainless Steel Cotter Pin (2 pack)	$8.66	View on RCPW
35	50912	Push Spreader Handle	$81.00	View on RCPW
36	50917	Handle Grip	$8.66	View on RCPW
37	50937	Gate Handle	$41.91	View on RCPW
38	50936	Gate Handle Bracket	$18.79	View on RCPW
39	50918	Gate Actuator Rod	$11.53	View on RCPW
40	50940	Red Handle Cover	$15.89	View on RCPW
41	50953	.0585" x 1-1/8" Stainless Steel Hairpin	$15.89	View on RCPW
42	50909	Frame Stand	$114.29	View on RCPW
43	D5933	Gate Cam	$8.67	View on RCPW
44	50945	Pivot Bolt SS	$17.33	View on RCPW
44a	50945	Pivot Bolt SS	$17.33	View on RCPW
45		Discontinued
46	50913	WB Gate Track	$15.89	View on RCPW
47	50942	Gate Link	$8.66	View on RCPW
48	50938	Walk Behind Spreader Gate Adjustment Stop	$8.66	View on RCPW
49		Discontinued
50	50956	5/16 x 2-1/2" Stainless Steel Hex Cap Screw	$7.21	View on RCPW
51	50949	1/4-20 x 1/2" Stainless Steel Hex Cap Screw	$7.21	View on RCPW
52		Discontinued
52a		Discontinued
52b		Discontinued
53	D5942-1	1/4"-20 Hex Stainless Nut	$1.23	View on RCPW
53a	D5942-1	1/4"-20 Hex Stainless Nut	$1.23	View on RCPW
53b	D5942-1	1/4"-20 Hex Stainless Nut	$1.23	View on RCPW
54	50911	Stainless Steel Hex Cap Screw 1/4-20 x 1-3/8 (5 pack)	$8.66	View on RCPW
55	50944	.279 x .030 x .355 Stainless Steel Spring	$8.66	View on RCPW
56	50939	#10-32 Weld Nut	$7.21	View on RCPW
57	50958	#10-32 Waxed Stainless Steel Nylock Nut	$7.21	View on RCPW
57a	50958	#10-32 Waxed Stainless Steel Nylock Nut	$7.21	View on RCPW
57b	50958	#10-32 Waxed Stainless Steel Nylock Nut	$7.21	View on RCPW
58	50908	Stainless Steel Hex Cap Screw #10-32 x 5/8" (5 pack)	$8.66	View on RCPW
59	50948	1/4-20 x 2-1/4" Stainless Steel Hex Cap Screw	$8.66	View on RCPW
60	50971	5/16"-18 Nylox Stainless Steel Nut (5 pack)	$7.21	View on RCPW
